38

Handycam Station DCRA-C171
Input/Output connectors

Audio/Video output

10 pin connector
Video signal: 1 Vp-p, 75

Ω (ohms)

Luminance signal: 1 Vp-p, 75

Ω (ohms)

Chrominance signal: 0.286 Vp-p, 75

Ω (ohms)

Audio signal: 327 mV (at load impedance
47 k

Ω (kilohms)), Output impedance less than

2.2 k

Ω (kilohms)

USB jack

mini-B

AC Adaptor AC-L200/L200B

Power requirements

Sony handycam

AC 100 - 240 V, 50/60 Hz

Current consumption

0.35 - 0.18 A

Power consumption

18 W

Output voltage

DC 8.4 V*

Operating temperature

0°C to + 40°C (32°F to 104°F)

Storage temperature

-20°C to + 60°C (-4°F to + 140°F)

Sony Handycam Dcr Sr42 Handbook

Dimensions (Approx.)

48 Ч 29 Ч 81 mm (1 15/16 Ч 1 3/16 Ч 3 1/4
in.)(w

×h×d) excluding the projecting parts

Mass (Approx.)

170 g (6.0 oz) excluding the power cord

* See at the label of AC Adaptor for other

specifications.

Rechargeable battery pack
NP-FH40 (DCR-SR42/SR62/SR82)

Maximum output voltage

DC 8.4 V

Output voltage

DC 7.2 V

Capacity

4.9 wh (680 mAh)

Dimensions (Approx.)

31.8

Ч 18.5 Ч 45.0 mm

(1 5/16

Ч 3/4 Ч 1 13/16 in.)(w×h×d)

Mass (Approx.)

45 g (1.6 oz)

Operating temperature

0°C to + 40°C (32°F to 104°F)

Type

Li-ion

NP-FH60 (DCR-SR200/SR300)

Maximum output voltage

DC 8.4 V

Output voltage

DC 7.2 V

Capacity

7.2 wh (1 000 mAh)

Dimensions (Approx.)

31.8

Ч 33.3 Ч 45.0 mm

Sony

(1 5/16

Ч 1 5/16 Ч 1 13/16 in.)(w×h×d)

Mass (Approx.)

80 g (2.9 oz)

Operating temperature

0°C to + 40°C (32°F to 104°F)

Type

Li-ion

Sony Dcr Sr42 Manual

Design and specifications are subject to change
without notice.

Advertising
This manual is related to the following products:

DCR-SR300, DCR-SR82, DCR-SR300C, DCR-SR200, DCR-SR200C, DCR-SR42, DCR-SR82C, DCR-SR42A

Popular Brands
Popular manuals
Advertising

5

Notes

DCR-SR42, DCR-SR62, DCR-SR82, DCR-SR200
and DCR-SR300 are to be used with the Handycam
Station Model DCRA-C171 and AC Adaptor
Model AC-L200/L200B.

CAUTION

Sony Handycam Dcr Sr42 User Manual

You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.

Note

This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment

and receiver.

– Connect the equipment into an outlet on a

circuit different from that to which the receiver
is connected.

– Consult the dealer or an experienced radio/TV

technician for help.

The supplied interface cable must be used with the
equipment in order to comply with the limits for a
digital device pursuant to Subpart B of Part 15 of
FCC Rules.

For the State of California, USA only

Perchlorate Material - special handling may
apply, See

www.dtsc.ca.gov/hazardouswaste/perchlorate

Sony Handycam Dcr-sr42 Charger

Perchlorate Material: Lithium battery contains
perchlorate.

Declaration of Conformity

Trade Name: SONY
Model No.: DCR-SR82
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo, San Diego, CA
92127 U.S.A
Telephone number: 858-942-2230
This device complies with Part 15 of the FCC
Rules.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.

Declaration of Conformity

Trade Name: SONY
Model No.: DCR-SR200
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo, San Diego, CA
92127 U.S.A
Telephone number: 858-942-2230
This device complies with Part 15 of the FCC
Rules.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.

Declaration of Conformity

Trade Name: SONY
Model No.: DCR-SR300
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo, San Diego, CA
92127 U.S.A
Telephone number: 858-942-2230
This device complies with Part 15 of the FCC
Rules.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.
